Wisman's PRC modular high voltage power supply is ideal for OEM usage. It is specifically designed to meet the needs of applications requiring a hot switched reversible output voltage. The output polarity of the unit can be quickly and safely reversed via the Polarity Control Signal provided on the interface connecter.
     Both the output voltage and current are fully adjustable via ground referenced remote programming signals such that 0 to 10Vdc corresponds to 0 to 100% rated output voltage and current.
     Remote motioning functionality is provided by voltage and current test points such that 0 to 10Vdc corresponds to 0 to 100% rated voltage and current. Additionally remote polarity and mode indicators provide a compre-hensive overview of power supply operation.
     An optionalUSB 2.0\RS-232 or RS-422 is available .
TYPICAL APPLICATIONS:
       Electrospinning
       Mass Spectrometry
       Capillary Electrophoresis
       Electrostatic Research
       DNA Analysis
       Microchip Electrophoresis
       Electrostatic Chuck (E-Chuck)
OPTIONS:
       USB          USB Interface
       RS232      RS-232 Interface
       RS422      RS-422 Interface
       5VPM        0 to 5 Volt Programming and Monitor Scaling
SPECIFICATIONS:
        Input:
                 +24Vdc±10% .
        Output:
                 See"CZE SELECTION TABLE"
Polarity:
          Auto reversible via command
Power:
         10 watts, maximum
Voltage Regulation:
         Load: 0.01% of output voltage no load to full load.
         Line: ±0.01% for ±10% change in input voltage.
Ripple:
         0.1% Vp-p
Stability:
         0.02% per 8 hours after 1/2 hour warm-up.
Environmental:
         Operational: 0°C to +40°C
         Storage: -40°C to +85°C
Humidity:
         10% to 85% RH, non condensing
Cooling:
          Free air Convection
Dimensions:
          3.5"H x 5.0”W x 10.0”D
         (89.00mm x 127.00mm x 254.00mm)
Interface Connector:
          25 pin male D connector
